Honeywell DVC100 (M) MK2 User Manual

INSTALLATION (CONT)
Searchpoint Excel
16
Terminal
Number
Gas Detector Wiring Field Wiring
Function Colour
1 - - +24VDC SUPPLY
2 +24V Red -
3 - - 0V - Supply
4 0V Black -
5 - - 4-20mA Output
6 4-20mA White -
7 RS485 A Orange -
8 RS485 B Blue -
9 - - Modbus Drain
10 - - Modbus A
11 - - Modbus B
12 - - -
Earth
Terminal
Earth Green /
Yellow
Earth / Barrier
Earth
