5 FC1: Operation for Legally Relevant Functionalities
That means that the Vb counter is highlighted, marked with a preceding
special icon
and displayed using a larger font size (cf. Figure 7).
Figure 7: Display indication of Vb (fiscal display)
After starting the FC1 device, the basic display, i.e. the fiscal display of the
first
Flow Conversion AFB, is invoked. For activating the fiscal display of
any other Flow Conversion AFB, you have to navigate to the home
display at first. Once in the home display, activate the button that represents
the
Flow Conversion AFB you are interested in. For switching back to
the basic display, you may either activate the corresponding AFB button or
the button labeled .
In most FC1 displays, there are labels that are designed as hyperlinks.
Hyperlinks are underlined and displayed in blue color. Using these hyper-
links is the most intuitive way for switching to subordinate displays showing
further values and results.
Figure 8 shows an example of a Flow Conversion fiscal display; Table
10 lists the target displays of the available hyperlinks as well as the values
and results included.
