Honeywell ERX - Parameter Item List (Alarm Limits P1 P2); P1 Pressure Alarm Limit Configuration; P2 Pressure Alarm Limit Configuration; Temperature Alarm Limit Configuration

49

Item Item Name & Description
553 P1 Pressure High Alarm Limit
The pressure reading that automatically produces a high-pressure alarm. This value is a
user selectable item and is normally set somewhere between 50 & 100% of transducer
range.
Default: 111.00
554 P1 Pressure Low Alarm Limit
The pressure reading that automatically produces a low-pressure alarm. .
Default: -1.00
555 P2 Pre
ssure High Alarm Limit
The pressure reading that automatically produces a high-pressure alarm. This value is a
user selectable item and is normally set somewhere between 50 & 100% of transducer
range.
Default: 222.00
556 P2 Pressure Low Alarm Limit
The pressure reading that automatically produces a low-pressure alarm. .
Default: -1.00
557 Temperature High Alarm Limit
The temperature
reading that automatically produces a high-temperature alarm. This
value is a user selectable item.
Default: 165.00
558 Temperature Low Alarm Limit
The temperature reading that automatically produces a low-temperature alarm. .
Default: -35.00
Alarm Status Indicators for items 559 through 568:
Code Value
Default: 00000000 No alarm
11111111 Alarm
A 50-millisecond alarm pulse,
transmitted out the alarm channel occurs at the time the recorder
alarms. All alarms must be cleared before the recorder will again output a 50-millisecond alarm
pulse.
559 P1 High Pressure Alarm
Code Value
Default: 00000000 No alarm
11111111 Alarm
560 P1 Low Pressure Alarm
Code Value
Default: 00000000 No alarm
11111111 Alarm
