Commissioning
The LCM is commissioned using a dedicated programme running on a Windows-based computer. Commissioning settings may then be directly uploaded from
the computer to the LCM or transferred to an HP2000 hand-held programmer for easy upload on site.
Communication from the PC can be by means of a USB infrared transceiver which can signal directly to the LCM’s on-board infrared port over a short range or via
any attached presence detector from beneath (range: 1-3m).
The main parameters for configuration are tabulated below. These parameters may be re-programmed any number of times and all settings will be retained in
the event of a power loss.
SELV Switch Options Description
Sustain Causes assigned channels to act as if an occupancy detector continues to detect occupancy
Brighten Raises light level . Works only with dimmable ballasts.
Dim Lowers Light level . Works only with dimmable ballasts.
Off Turns lamp OFF
Scene 01..06 Recalls Scene assigned (any scene 01 to 06 as configured)
On Turns lamp ON
Partition Initiates logical partition of a room. Refer to AN4002 for more details
OneSwitch
Simple momentary push-to-make wallswitch that can be used to raise or lower the lighting level or toggle the output of
the unit ON or OFF. Short press toggles output ON and OFF; long press will ramp the light level Up or Down.
On-Dim Short Press will turn the output ON, long press will lower the light level
Off-Brighten Short Press will turn the output OFF, long press will raise the light level
On-Brighten Short Press will turn the output ON, long press will raise the light level
Off-Dim Short Press will turn the output OFF, long press will lower the light level
Emergency Tst Initiates manual test of emergency luminaire by turning OFF the Maintained Live
Emergency End Restores Maintained Live to end the Emergency Test
Description of Switch Input Options:
-6-
PARAMETERS OPTIONS
Per Box Parameters:
Switch A: 1-5, Switch B: 1 -5,
Switch 6A*, 6B*, 7A*, 7B*
User may choose any option for Switch A or Switch B from following:
Sustain / Brighten / Dim / Off / Scene 01..06 / On / Partition / OneSwitch / On-Dim / Off-Brighten / On-Brighten / Off-Dim /
Emergency Test / Emergency End (See separate table for detailed description of Switch Input options)
Detector 1-5: Range Max 100%, Max 75%, Max 50%
High 100%, High 75%, High 50%
Med 100%, Med 75%, Med 50%
Low 100%, Low 75%, Low 50%
Min 100%, Min 75%
Per Channel Parameters:
Ballast Type Non-Dimming, 1% DSI, 3% DSI, 10% DSI, 1% DALI, 3% DALI, 10% DALI
Assigned Detectors Detectors 1-5: Assigned or not assigned to this channel
Assigned Photocell Photocell 1-5 (in Detectors 1-5): Assigned or not assigned to this channel
Assigned Switches Switch A & B: Assigned or not assigned to this channel
Power Up On / Off
Response Auto, Manual/Bus, Manual only
Off Delay (Main Time Delay) 10 seconds to 96 hours / Disabled
Bus Connect Yes / No
Zones 1-4 Zone number 1-100
Corridor 1-2: Begin Zone number 1-100
Corridor 1-2: End Zone number 1-100
Global 1-2 Rx Yes / No
Manual I/P (Local/Share for Each Switch)
Obey locally only / Obey locally and transmit command on MLS bus
Start Lamps Max / Min
Entry Scene Scene 1-6
Lamp Max
100%, 90%, 80%, 70%, 50%, 45%, 40%, 35%, 30%, 25%, 20%, 15%, 10% Note: Not required for VF or SELV Outputs
When Vacant
Off until next occupancy detection
(Turn-Off Options)
Minimum, 25% or Scene 6 until next occupancy detection
Minimum, 25% or Scene 6 for 3 x Off Delay
Minimum, 25% or Scene 6 until the building is empty
Fade to Off Yes / No
Bright Out Yes / No
Photocell
Regulate (100%, 90%, 80%, 70%, 60%, 50%) / Passive / Active / Disabled Note: Not required for VF or SELV Outputs
Set-Point Low (Photocell Lower Threshold)
0-1024 (used in Regulating Scene 1) Note: Not required for VF or SELV Outputs
Set-Point High (Photocell Upper Threshold)
0-1024 (used in Regulating Scene 1) Note: Not required for VF or SELV Outputs
Scene 2 Output 0-100%
Scene 3 Output 0-100%
Scene 4 Output 0-100%
Scene 5 Output 0-100%
Scene 6 Output 0-100%
100 Hour Burn-in Burn-in 100hrs/Cancel/Resume - See Application Note AN4028
* Planned
