DISTRIBUTED I/O – PRODUCT DATA
13 EN0B-0090GE51 R0316
Table 11. Relation between contact position and logical status for the XFL524B
relay on/off NO/NC attribute logical status LED status
on NO 1 on
off NO 0 off
on NC 0 off
off NC 1 on
Table 12. L
ONMARK Object NVs for the XFL524B
NV name type range description
nviValue SNVT_switch Receives the value for the output channel.
nvoFeedback SNVT_switch
Transmits the feedback value of the Actuator Object. If
the manual override switch is set to auto, or if the
manual override module is not plugged in, the feedback
output reflects the value of nviValue. As soon as the
manual override switch is set to either manual position,
the Actuator Object adopts this manual value; then, the
state of nvoFeedback will be 0xFF (invalid) and the
value field will contain the actuator position.
If the manual override switch is in the automatic posi-
tion, data is transmitted whenever nviValue is written. If
in the manual position, data is transmitted whenever
the manual position is changed.
nvoManCnt SNVT_count 0 to 65535
Transmits the number of manual switching operations.
Each transition from the "auto/manual on/manual off"
state to any other state is counted by incrementing this
NV.
nvoDiagnose SNVT_count 0 to 65535
Counts the number of times the internal filter for
smoothing the signal from the manual override switch
board has been active.
UCPTSensorConfig
0 = not used
1 = binary (default)
Specifies whether an Actuator Object is processed or
not. If set to 0, the value is not updated.
