Honeywell EXCEL 5000 Product Data

DISTRIBUTED I/O – PRODUCT DATA
EN0B-0090GE51 R0316 24
XFL52xB modules can be used as third-party devices with
other L
ONMARK compliant products, independently of an Excel
500 controller.
IMPORTANT:
Full L
ONMARK functionality requires an Excel 500
controller with controller firmware version 2.04.xx (or
later), a 3120E5 Neuron chip, and Distributed I/O
modules XFL52xB.
An Excel 500 controller with controller firmware
version 2.04.xx (or later) and a 3120E5 Neuron chip
will commission earlier versions of Distributed I/O
modules (XFL52x, XFL52xA), but only in the local
mode (max 16 modules per CPU and no other
controllers on the L
ONWORKS bus).
Distributed I/O modules XFL52xB can be used with
older versions of Excel 500 that support Distributed
I/O, but only if the modules are switched into a
different mode. This is accomplished by pressing the
service pin while simultaneously turning the rotary
HEX switch. This mode can be cancelled by pressing
the service pin for more than three seconds.
Table 17. Controller compatibility (non-L
ONMARK CPUs/application modules, date code older than week 44 in 2000)
controller type controller firmware
open
LONWORKS
functionality
CPU autobinding
1
with
CARE LONWORKS
binding
LM4W
binding
XFL52x XFL52xB
XC5010C, XCL5010
2.00.xx – 2.03.xx not possible local local not possible not possible
2.04.xx not possible local local/shared not possible not possible
2.06.xx not possible local local/shared not possible not possible
XD50C-F, XD50C-FC 2.08.xx possible not possible not possible possible possible
XD50C-FCL, XD50C-FL
2.08.xx possible not possible not possible possible possible
2.08.xx possible not possible not possible possible possible
1
See section "Operating Modes" on page 25 for definitions of the terms "local," "shared," "open," and "shared/open."
Table 18. Controller compatibility (L
ONMARK CPUs/application modules, date code younger than week 44 in 2000)
controller type controller firmware
open
LONWORKS
functionality
CPU autobinding
1
with
CARE LONWORKS
binding
LM4W
binding
XFL52x XFL52xB
XCL8010A
2
3.00.xx in use not possible not possible possible possible
3.00.xx not in use not possible not possible not possible not possible
XC5010C, XCL5210C,
XCL5010
2.00.xx – 2.03.xx not possible local local not possible not possible
2.04.xx in use not possible shared/open not possible possible
2.04.xx not in use local local/shared not possible possible
2.06.xx in use not possible not possible possible possible
2.06.xx not in use local local/shared not possible not possible
XD50C-F, XD50C-FC
2.08.xx in use not possible not possible possible possible
2.08.xx in use not possible not possible possible possible
2.08.xx in use not possible not possible possible possible
2.08.xx in use not possible not possible possible possible
XD50C-FCL, XD50C-FL
2.08.xx in use not possible not possible possible possible
2.08.xx in use not possible not possible possible possible
2.08.xx in use not possible not possible possible possible
2.08.xx in use not possible not possible possible possible
1
See section "Operating Modes" on page 25 for definitions of the terms "local," "shared," "open," and "shared/open."
2
The XCL8010A is likewise not capable of CPU autobinding with Excel 800 I/O modules.
