3EN
INSTALLATION THROUGH A WINDOW
It is important that the installation instructions below are followed for successful installation of this
Portable Local Air Conditioner. Please call Customer Support if you have any difficulties or questions
regarding these installation procedures.
Installation Kit:
Installation Steps:
The Unit Connector
2
and the Exhaust Hose
4
are pre-assembled inside the package.
1.
1. Nozzle (1 Set) 4. Exhaust Hose (1 Piece)
2. Unit Connector (1 Piece) 5. Flange Fixture + Hole Cover (1 Piece)
3. Nozzle Connector (1 Piece)
1 3
x1
x1 x1
2
Exhaust Hose:
Length: 10.6" to 59" (27 cm to 150 cm)
5
x1
4
x1
To Next Page
