4
INSTALLATION THROUGH A WINDOW (CONTINUED)
Take the above pre-assembled Exhaust Hose and install the Nozzle Connector
3
on the opposite
end of the Unit Connector. Twist the Nozzle Connector anti-clockwise.
Clip the Nozzle
1
to the Nozzle Connector
3
end of the composite Exhaust Hose that you have
assembled in the above steps.
2.
3.
