Accessing the Camera

Figure 2-6 Device List

Assigning a New IP Address to Your Camera

The current IP address of your camera appears in the IP ADDRESS column of the devices list.

If you want, you can assign a new static IP address to the camera.

Select the target device(s) as shown in Figure 2-6, click and the following figure is

displayed:

Figure 2-7 IP Assignment
