Configuring PTZ Settings

After all settings are completed, click SAVE.

On the PTZ panel of live view, click on the PTZ panel (see Figure 3-9) in the main page.

If there is an intruder, the camera will follow and track the intruder. To stop the auto tracking,

click any buttons on the PTZ panel, or a mouse click takes place on a view window.

You can choose to perform other functions, such as pan or patrol, simply by clicking their

buttons on the PTZ panel while the camera is performing the auto tracking function.
