Introduction
3
Figure 1-2 HEW2PR1/HEW4PR3/HEW2PRW1/HEW4PRW3 Components
H2W2PRV3/H2W4PRV3 Micro Dome Cameras
Figure 1-3 H2W2PRV3/H2W4PRV3 Dimensions
Figure 1-4 H2W2PRV3/H2W4PRV3 Components
1.98" (50.3 mm)
4.17" (106.0 mm)
1 Lens
2 Camera module
3 Camera enclosure
4 12 VDC connector
5 LAN connector
1 Enclosure
2 Dome Cover
3 LAN connector
4 12 VDC connector
