Transport,installationandstart‐up
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  38
5.5 Startingupthegaspressureregulator

Riskofinjuryposedbyburstingpartsintheeventthattheyaresubjectedtopressurein
thewrongdirection
Thedevicehasbeendesignedforaspecificdirectionofflow,whichislabeledonthedevice.
Subjectingthedevicetopressureinthewrongdirectionmayresultinseriousinjurycaused
byburstingparts.
 Pressurizethesystemonlyontheinletside.

Afterbeinginadepressurizedstate,theadjustmentprocessforthegaspressureregulator
willberelativelysluggish.Duringcommissioning,alwaysmakesuretowaitbetweenthe
individualstepsuntilthedesiredstateisreached.


Thenumbershavethefollowingmeaning:
No. Meaning
1 Inletstopvalvearmature
2 Inletpressuregauge
3 Gaspressureregulator
4 Loadingpressuregauge
5 Blowdownlineshut‐offdevice
6 Outletpressuregauge
7 Outletstopvalvearmature

Makesurethatthefollowingrequirementsaremet:
 Thesystemhasbeenchecked,isfullyfunctional,andhasnoleaks.
 Theinletandoutletshut‐offdevicesforthegasregulatinglinesectionareclosed.
 Theshut‐offdevicesfortheblowdownlinesareclosed.
 Theinletpressureispresentupstreamoftheinletshut‐offdevice.Detailsaboutthe
operatingpressurecanbefoundinthetechnicalspecifications(seepage17).
 Thesystemisdepressurizedbetweentheinletshut‐offdeviceandtheoutletshut‐off
device.

Pressurizedparts
Basicpointers
Gasregulatinglinecom‐
ponents
Requirements
