Honeywell HR92 User Manual

4
Binding at the HR92
The radio symbol flashes during binding.
If binding was successful,
success
is displayed.
Afterwards the main display is shown.
When
sync
is shown in the display, the radiator
controller is synchronizing with the central operating
device.
HR92 receives the data from the central operating
device.
i
Synchronization can take up to 4 minutes until the
current room setpoint temperature is displayed at the
HR92.
If BINDING is not successful, it is terminated
automatically after approx. 10 minutes. – or –
To cancel BINDING, select Exit using the adjustment
dial and confirm with the button.
i
If several HR92 radiator controllers in one room
(zone) are to be controlled by the central operating
device, it is possible to activate BINDING at all radiator
controllers simultaneously. BINDING then only has to
be carried out once.
Failed binding/insufficient data transfer
Binding has failed when the radio symbol
disappears and
failed
is displayed.
The data transfer output may be insufficient. This can be
caused by metallic objects or further radio devices.
fEnsure that the distance to radio devices such as
radio headphones, cordless phone, etc. amounts to at
least 1 m.
fEnsure that the distance to metallic objects is
sufficient.
fIf radio interference cannot be eliminated, select a
different mounting location for the room unit and
repeat binding.
Clearing binding at the HR92
1. Press the button briefly.
2. Hold the button pressed for 5 seconds.
3. Select
bind
using the adjustment dial and keep the
button pressed until
cleared
is displayed.
Binding is deactivated.
Radio test
1. Press the button briefly.
2. Hold the button pressed for 5 seconds.
3. Select
rf check
using the adjustment dial and
confirm with the button.
checking
is displayed (flashing) in the display.
checking
The radiator controller is ready to receive radio signals
from the central operating device.
i
Please read the operating instructions of your central
operating device for further information about the
radio test.
The field strength is displayed as a bar and a number
while the radio signal is being received.
signal
05
5 bars Field strength
excellent
3 bars Field strength good
1 bars Field strength weak
Radio test at operating devices with 2-way
communication
If the central operating device can transmit and receive
(2-way communication), like the evotouch, the field
strength can be queried directly at the radiator controller
without activating the radio test in the central operating
device.
1. Press the button briefly.
2. Hold the button pressed for 5 seconds.
3. Select
rf check
using the adjustment dial and
confirm with the button.
checking
is displayed (flashing) in the display.
4. Press the button again.
The field strength is displayed as a bar and a number
while the radio signal is being received.

Honeywell HR92 Specifications

General

Display	LCD with backlight
Power Supply	2 x AA batteries
Communication	Wireless
Frequency	868 MHz
Temperature Control Accuracy	±0.5°C
Battery Life	Approximately 2 years
Range	Up to 30 meters
Connection	M30 x 1.5
Compatibility	Evohome systems
