3EN
INSTALLATION
It is important that the installation instructions below are followed for successful installation of this
Portable Air Conditioner. Please call Customer Support if you have any difficulties or questions
regarding these installation procedures.
Installation Kit:
1. Window Bracket Kit (1 Set) 5. Exhaust Hoses (2 Pieces)
2. Window Bracket Panel Adapters (2 Pieces) 6. Butterfly Screws (2 Pieces)
3. Exhaust Hose Connectors (2 Pieces) 7. Insulation Tape (gray, adhesive) (1 Piece)
4. Hole Covers (2 Pieces) 8. Insulation Tape (black, adhesive) (1 Piece)
9. Foam Insulation Pads
(non-adhesive)
(2 Pieces)
1
x1
3
x2
4
x2
6
x2
7
x1
x2
2
x2
5
x1
8 9
x2
To Next Page
