7
8. The Portable Air Conditioner is now ready to use.
INSTALLATION (CONTINUED)
6. Connect the window bracket to the window.
7. Position the non-adhesive foam pads on both edges that are not covered by the foam adhesive
tape to seal gaps and prevent air and insects from entering into the room.
Horizontal Sliding Window Vertical Sliding Window
Foam
Insulation Tape
(adhesive)
Foam
Insulation Pad
(non-adhesive)
Foam
Insulation Pad
(non-adhesive)
Foam Insulation
Tape (adhesive)
EN
