Honeywell IS3016A User Manual

- 5 -
SPECIFICATIONS
Range: 16 m x 22 m
Power: 9.0 - 15 VDC; 9 mA typical, 11 mA maximum, 12 VDC;
AC Ripple: 3 V peak-to-peak at nominal 12 VDC
Alarm Relay: Energized Form A; 30 mA, 25 VDC, 22 Ohms
resistance maximum. Alarm Relay Duration: 3 seconds
Trouble Relay: Energized Form B; (NC) 30 mA, 25 VDC; 22 Ohms
resistance maximum
Tampers: Cover & Wall; (NC with cover installed) Form A;
30 mA, 25 VDC; Magnetic field
RFI Immunity: 15 V/m, 80 MHz – 2.7 GHz
PIR White Light Immunity: 10,000 Lux typical
Fluorescent light filter: 50 Hz / 60 Hz.
Operating Temperature: -10° to 55° C
Relative Humidity: 5 to 95%; non-condensing
Temperature Compensation: Advanced Dual Slope
Dimensions: 11.6 cm H x 7.0 cm W x 4.3 cm D
Weight: 118 g (net weight)
ACCESSORIES
SMB-10
(P/N 0-000-110-01)
Swivel Mount Bracket
SMB-10C
(P/N 0-000-111-01)
Swivel Mount Ceiling Bracket
SMB-10T
(P/N 0-000-155-01)
Swivel Mount Bracket w/Tamper
Note: The accessories are not covered by certifications.
APPROVAL LISTINGS
EN50131-2-2:2008, Security Grade 3,
Environmental Class II.
Suitable for connection to an EN 60950
Class II Limited Power Source.
PD6662:2010
Note: In EN 50131-2-2 compliant installations, mount the sensor at 2.3m,
do not use o
nly the right side corner mounting holes, enable look down
and lock the sensor housing with the cover lock (see “[EN]” where
noted in Steps 1-4).
Important: The sensor should be tested at least once each year.
NF&A2P 3 boucliers (référentiel
NF324-H58) et conforme aux normes
EN50131-2-2 et RTC50131-2-2
IP30 IK04
N° de certificat: 2631420016
Organisme de certification:
CNPP Cert. : www.cnpp.com et
AFNOR Cert.: www.marque-nf.com
Honeywell Security Group - BP1219
1198 avenue du docteur Maurice Donat
Sophia Antipolis
06254 Mougins Cedex.
TEL: +33.4.92.94.29.50
FAX: +33.4.92.94.29.60
INCERT: B-893-0013
Corrente
norminale:
12 =
Corrente
massima
assorbita:
11 mA
LARMKLASS
4
