Honeywell krom schroeder IFD 258 User Manual

IFD 258 · Edition 03.12l
18
44 ซ.บรมราชชนนี 70 ถ.บรมราชชนนี ศาลาธรรมสพน์ ทวีวัฒนา กทม. 10170.
website: https://www.add-furnace.com/ โทร: 02-888-3472
Line ID: @add11 e-mail: add028883472@gmail.com
4 Parameters
Description
Parameter
Value range
Factory default settings
Adjustable*
Burner flame signal
01
0 – 25 μ A
Burner switch-off threshold
04
2 – 20 A
2 µA
1)
Burner restart
12
0; 1
0
2)
Safety time during operation for V1 and V2 t
SB
14
1; 2 s
3)
Burner safety time on start-up t
SA
22
3; 5; 10 s
3)
Last fault
81
Second to last occurring fault
82
Third to last occurring fault
83
…
Tenth to last occurring fault
90
1)
Via potentiometer in lower section of housing.
2)
Via switch in lower section of housing.
3)
Quote in your order.
On parameterization, ensure that the program sequence matches the application. Select the parameters so that
the burner can be operated as intended in all operating phases.
4 . 1 S c ann i n g t h e p ar am e t er s
During operation, the 7-segment display shows the program status, see page 16 (Program status and fault
messages).
The flame signal and all following parameters of the IFD can be scanned one after the other by repeatedly pressing
the Reset/Information button (for 2 s).
In the event of a fault, the IFD halts the program run, the display blinks and it then displays the cause of the fault in
coded form.
