LYNX Touch Installation and Setup Guide
- 11 -
AC Power and Backup Battery
5000-100-093-V2
OR
RETAINER
SCREW
RETAINER
SCREW
BATTERY
CABLE
CHANNEL
BATTERY PACK
(P/N 300-03866/
LYNXRCHKIT-SHA)
BATTERY PACK
(P/N 300-03864-1/
LYNXRCHKIT-SC)
BATTERY
WIRE ROUTING
CLIPS (3)
L5200 Battery Installation
7000-100-010-V0
OR
RETAINER
SCREW
RETAINER
SCREW
BATTERY PACK
(P/N 300-03866/
LYNXRCHKIT-SHA)
BATTERY PACK
(P/N 300-03864-1/
LYNXRCHKIT-SC)
BATTERY
CABLE
CHANNEL
BATTERY
WIRE ROUTING
CLIPS (3)
L7000 Battery Installation
