LYNX Touch Installation and Setup Guide
- 76 -
Zone Programming Default Values
Zone Programming Notes
1. Zone 1 is a hardwire zone; Zones 95, 96 and 99 are keypad panics.
2. For the LYNX Touch L5200/L5200CN Zones 2 to 64 are RF zones (Zones 46 to 48 are reserved for Garage Door Zones); Zones 140-155
are RF Button Zones and 180-185 are Temperature Zones.
3. For the LYNX Touch L7000/L7000CN Zones 2 to 70 are RF zones (Zones 45 to 48 are reserved for Garage Door Zones); Zones 140-163
are RF Button Zones and 180-187 are Temperature Zones.
4. The default values shown below are for the LYNX Touch L5200/L5200CN.
Zone Assignment/Alarm Response Types for Configuration 1
Zone
Number
Loop
Number
Device Type Response Type
Alarm
Report
Chime Supervision
Arm
Night
Zone Descriptor
1 --- New Not Used Yes Disabled End of Line n/a n/a
2 2 Door Entry Exit 1 Yes Standard Supervised n/a Front
3 2 Door Entry Exit 1 Yes Standard Supervised n/a Back
4 2 Window Perimeter Yes Standard Supervised n/a n/a
5 1 Motion Sensor Interior With Delay Yes Disabled Supervised No n/a
46 1 New Not Used No Standard Supervised n/a Main
47 1 New Not Used No Standard Supervised n/a Main
48 1 New Not Used No Standard Supervised n/a Main
140 3 4 Button Arm Away Yes Disabled Button n/a n/a
141 2 4 Button Disarm Yes Disabled Button n/a n/a
142 4 4 Button Arm Stay Yes Disabled Button n/a n/a
143 1 4 Button No Response No Disabled Button n/a n/a
144 3 4 Button Arm Away Yes Disabled Button n/a n/a
145 2 4 Button Disarm Yes Disabled Button n/a n/a
146 4 4 Button Arm Stay Yes Disabled Button n/a n/a
147 1 4 Button No Response No Disabled Button n/a n/a
180 --- Temperature Not Used Yes Disabled High Temp n/a n/a
181 --- Temperature Not Used Yes Disabled Low Temp n/a n/a
182 --- Temperature Not Used Yes Disabled High Temp n/a n/a
183 --- Temperature Not Used Yes Disabled Low Temp n/a n/a
184 --- Temperature Not Used Yes Disabled High Temp n/a n/a
185 --- Temperature Not Used Yes Disabled Low Temp n/a n/a
95 --- Fire Fire No Verification Yes Disabled Panic Trigger n/a n/a
96 --- Medical Not Used Yes Disabled Panic Trigger n/a n/a
99 --- Police 24-Hour Silent Yes Disabled Panic Trigger n/a n/a
Zone Assignment/Alarm Response Types for Configuration 2
Zone
Number
Loop
Number
Device Type Response Type
Alarm
Report
Chime Supervision
Arm
Night
Zone Descriptor
1 --- New Not Used Yes Disabled End of Line n/a n/a
2 2 Door Entry Exit 1 Yes Standard Supervised n/a Front
3 2 Door Entry Exit 1 Yes Standard Supervised n/a Back
4 2 Door Entry Exit 1 Yes Standard Supervised n/a Garage
5 1 Motion Sensor Interior With Delay Yes Disabled Supervised No n/a
6 1 Smoke Detector Fire No Verification Yes Disabled Supervised n/a n/a
46 1 New Not Used No Standard Supervised n/a Main
47 1 New Not Used No Standard Supervised n/a Main
48 1 New Not Used No Standard Supervised n/a Main
140 3 4 Button Arm Away Yes Disabled Button n/a n/a
141 2 4 Button Disarm Yes Disabled Button n/a n/a
142 4 4 Button Arm Stay Yes Disabled Button n/a n/a
143 1 4 Button No Response No Disabled Button n/a n/a
144 3 4 Button Arm Away Yes Disabled Button n/a n/a
145 2 4 Button Disarm Yes Disabled Button n/a n/a
146 4 4 Button Arm Stay Yes Disabled Button n/a n/a
147 1 4 Button No Response No Disabled Button n/a n/a
180 --- Temperature Not Used Yes Disabled High Temp n/a n/a
181 --- Temperature Not Used Yes Disabled Low Temp n/a n/a
182 --- Temperature Not Used Yes Disabled High Temp n/a n/a
183 --- Temperature Not Used Yes Disabled Low Temp n/a n/a
184 --- Temperature Not Used Yes Disabled High Temp n/a n/a
185 --- Temperature Not Used Yes Disabled Low Temp n/a n/a
95 --- Fire Fire No Verification Yes Disabled Panic Trigger n/a n/a
96 --- Medical 24-Hour Auxiliary Yes Disabled Panic Trigger n/a n/a
99 --- Police 24-Hour Audible Yes Disabled Panic Trigger n/a n/a
