Honeywell Lynx Plus Programming Guide

- 2 -
TABLE OF CONTENTS
Data Fields................................................................................................................................................................3
✻56 Enhanced Zone Programming........................................................................................................................10
✻56 Enhanced Zone Programming Worksheet......................................................................................................13
✻80 Device Programming.......................................................................................................................................15
✻81 Zone Lists........................................................................................................................................................16
Powerline Carrier Device Worksheet for ✻80 and ✻81...........................................................................................17
✻83 Enhanced Sequential Mode ...........................................................................................................................18
✻84 Assign Zone Voice Descriptors.......................................................................................................................19
Vocabulary Index (for ✻84 Assign Zone Voice Descriptors) ..................................................................................19
✻85 Record Custom Voice Descriptors..................................................................................................................20
5800 Series Transmitter Loop Numbers Diagram ..................................................................................................21
Lynx Plus Summary of Connections Diagram........................................................................................................23
Refer to the Lynx Plus Series Installation and Setup Guide P/N 800-03858 or later for detailed
information on programming the system. The Installation and Setup Guide contains full descriptions for
all data fields.
UL
Lynx Plus is not intended for UL985 Household Fire applications unless a 24-hour backup battery
(P/N LYNXRCHKIT-HC or LYNXRCHKIT-SHA) is installed.
To Enter Programming Mode:
You may find it convenient to adjust the volume setting before entering the Programming Mode. This will allow
you to clearly hear feedback announcements or system beeps.
1. Power up, then depress [✻] and [#] both at once, within 50 seconds of powering up.
OR
Enter: Installer Code (4 + 1 + 1 + 2) plus 8 + 0 + 0. System will display “Entering Program Mode”.
Notes: 1. If a different Installer Code has been programmed, enter: the New Installer Code + 8 + 0 + 0.
2. If
✻98 was previously used to exit programming, the first method shown above must be used to re-
enter the program mode)
2. Upon entry into Program mode, data field “20 INSTALLER CODE” will be displayed (the first data field in
the system) and both keypad LEDs will flash.
To Program the Data Fields:
1. Press [✻] followed by the desired field number (e.g., ✻21), then make the required entry.
2. The keypad beeps three times after entering data, then displays the next data field in sequence.
3. For phone number and account number fields, press [
✻] to end the entry if less than number maximum
number of digits is entered.
4. To view data entered in field, press [#] plus the field that you wish to view (e.g., #21). The system will beep
three times and data programmed for that field will be displayed to the right of the field number. The system
will scroll through the data for longer numbers and a beep will sound after each number is displayed or
three times after the final digit is displayed.
5. To delete an entry, simply press [
✻] plus that field number and reenter the correct data. For phone number
and account number fields
✻40-✻44, ✻88 and ✻94, press [✻] + field number + [✻].
Interactive Menu Modes:
There are six interactive menu modes as listed below. To enter these modes, first enter Program mode. While in
Program mode, press [
✻] plus the mode number desired (e.g., ✻56).
✻56 Enhanced Zone Programming ...............For programming zone characteristics, report codes, etc.
✻80 Device Programming..............................For programming Powerline Carrier Devices
✻81 Zone List Programming..........................For programming zone lists for use with Powerline Carrier Devices
✻83 Enhanced Sequential Mode ...................For entering transmitter serial numbers
✻84 Assign Zone Voice Descriptors ..............For assigning voice descriptors to zones
✻85 Record Custom Voice Descriptors.........For recording custom voice descriptors
