- 15 -
✻
✻✻
✻80 DEVICE PROGRAMMING
Use this mode to program Powerline Carrier Devices or zone lists for Chime by Zone feature. It is also used to
program the Remote Services Multi-mode (e-mail) event triggers. Press
✻80 while in programming mode.
Note: Entering a number other than the one specified may give unpredictable results.
80
8080
80
DEVICE
DEVICE DEVICE
DEVICE
PROG
PROGPROG
PROG
MENU
MENU MENU
MENU
Powerline Carrier Device Programming
0 = Exit mode, upon which this prompt blinks.
1 = Enter mode
A01
A01A01
A01
DEVICE
DEVICE DEVICE
DEVICE
NUMBER
NUMBERNUMBER
NUMBER
Device Number
Enter the 2-digit device number to be programmed
01-08 = X10 device number
09-16 = Multimode (e-mail) event triggers
[✻] = Continue
00 = Exit Device Programming mode (displays blinking 80; enter ✻ + desired data field or
menu mode number)
b
DEVICE
DEVICE DEVICE
DEVICE
ACTION
ACTIONACTION
ACTION
Device Action
Enter the 1-digit action, 0-3, for the device being programmed (current action is displayed).
0 = No response 3 = Pulse on and off
1 = Close for 2 seconds [✻] = Continue
2 = Close and stay closed [#] = Return to previous prompt
C
CC
C
START
STARTSTART
START
EVENT
EVENT EVENT
EVENT
TYPE
TYPETYPE
TYPE
Start Event Type (If applicable)
Enter the 1-digit start event type, 0-3, for the device being programmed.
0 = Not used 3 = Trouble
1 = Alarm [
✻] = Continue
2 = Fault [#] = Return to previous prompt
d
START
STARTSTART
START
ZONE
ZONE ZONE
ZONE
LIST
LIST LIST
LIST
Start Zone List (If applicable)
Enter the 1-digit zone list number, 1-3, or 0 if not used, for the device being programmed.
[
✻] = Continue
[#] = Return to previous prompt
E
EE
E
START
STARTSTART
START
ZONE
ZONE ZONE
ZONE
TYPE
TYPETYPE
TYPE
Start Zone Type (If applicable)
Enter the 2-digit start zone type for the device being programmed (see Powerline Carrier
Device Worksheet for zone type/system operation codes later in this manual).
[
✻] = Continue
[#] = Return to previous prompt
F
FF
F
STOP
STOPSTOP
STOP
ZONE
ZONE ZONE
ZONE
LIST
LISTLIST
LIST
Stop Zone List (If applicable)
Enter the 1-digit zone list number, 1-3, or 0 if not used, for the device being programmed.
[
✻] = Continue
[#] = Return to previous prompt
1A
1A1A
1A
STOP
STOP STOP
STOP
ZONE
ZONEZONE
ZONE
TYPE
TYPE TYPE
TYPE
Stop Zone Type (If applicable)
Enter the 2-digit stop zone type for the device being programmed (see Powerline Carrier
Device Worksheet for zone type/system operation codes later in this manual).
[
✻] = Continue to Device Number prompt (A)
[#] = Return to previous prompt
