– 14 –
SYSTEM OVERVIEW
SYSTEM OVERVIEWSYSTEM OVERVIEW
SYSTEM OVERVIEW
About the Display and Indicators
ICON TEXT
DEFINITION
Fire OR
Fire Alarm
95 Fire
The fire icon is displayed with alternating text “Fire” and “Fire
Alarm 95 Fire”. “Fire Alarm” is also displayed in a red band
along the top of the screen.
Alarm 96
Medical
The Medical icon isplayed when a medical alarm is activated.
“Alarm” is also displayed in a red band along the top of the
screen.
(If programmed for display by your installer)
Alarm 99
Police
The alarm (bell) icon when a burglary alarm is activated.
“Alarm” is also displayed in a red band along the top of the
screen.
(If programmed for display by your installer)
CO Alarm
Displayed alternately with the alarm (bell) icon when a CO
alarm is activated.
“Alarm” is also displayed in a red band along the top of the
screen.
Cover
Tamper
A check system icon along with “Cover Tamper” is displayed
when a cover tamper has been detected. “Ready To Arm –
System Trouble” is displayed in a yellow band along the top of
the screen.
Reporter
Failure
The system has identified a problem with the telephone dialer.
Low
Battery
“Not Ready To Arm – System Trouble” is displayed in a yellow
band along the top of the screen. A low battery icon along with
“Low Battery” is displayed when the system’s backup battery
power is low.
90 RF Jam
Appears when the system has detected an RF jamming
condition or excessive interference.
94 Phone
Line Cut
Appears when the system has detected a loss of telephone
service.
AC Loss
Displayed when the system has lost AC power. “Ready To
Arm – System Trouble” is displayed in a yellow band along the
top of the screen.
