Honeywell MN10CES User Manual

7
INSTALLATION
Install the plastic hose with window bracket adapter and hose connector on both sides.
Ensure proper fit on both ends.
Adjust the window bracket as per width or height of your window and insert the plastic
pins to fix at the desired position.
Note : Do not install the window
bracket to your window. This step is
required only to adjust it to the
size of your window. The bracket
should be removed from the window
after the size is adjusted.
1
2
3
=
Connect the plastic hose to the hose connector on the back of the unit. Push-in then rotate
clockwise.
Plastic Pin
Plastic Pin

Honeywell MN10CES Specifications

General

Timer type	Digital
Noise level	50 dB
Variable power	Yes
Number of speeds	3
Airflow (high speed)	294 m³/h
Cooling capacity (max)	1000 BTU/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Hourly energy consumption (cooling)	- kWh
Display type	LED
Product color	Black, Silver

Weight and Dimensions

Depth	385 mm
Width	460 mm
Height	746 mm
Weight	29100 g
Package depth	475 mm
Package height	870 mm
Package weight	33800 g
