VRN PRESSURE INDEPENDENT CONTROL VALVES AND ACTUATORS
38-00032—01 6
Fig. 1. Valve Dimensions with MVN Actuator; see Table 5.
Table 5. Valve Dimensions with MVN Actuator.
Model Pipe Size Flow, gpm (m3/h) Dimensions in in. (mm)
Weight
lb. (kg)
Service Replacement
PartsNPT in. S.I. metric Min. Rating Max. Rating Full Port A B C D E F G
VRN2A 1/2 DN15 1.0 (0.23) 7.0 (1.6) 5.71
(145)
4.56
(116)
6.57
(167)
2.32
(59)
3.87
(98)
7.36
(187)
2.8 (71) 2.5 (1.1) Stem: 5112-19
5112-22 (SS);
Regulator:
8615-100 for 1-3 gpm;
8615-101 for 4-10 gpm
VRN2B 3/4 DN20 9.0 (2.0) 10 (2.3) 6.63
(168)
VRN2C 1 DN25 15.0 (3.4) 5.83
(148)
20 (4.5) 20 (4.5) 9.65
(245)
9.13
(232)
2.41
(61)
8.01
(203)
7.1 (3.2) Stem: 5112-20
5112-23 (SS);
Regulator:
8615-102
VRN2D 1–1/4 DN32 10 (2.3) 30 (6.8) 35 (7.9) 8.98
(228)
8.79
(223)
M34967
A
C
F
D
B
E
CLEARANCE ABOVE ACTUATOR 3/4 (19)
G
