8 NFN-GW-EM-3 Installation and Operation Manual — P/N LS10017-000NF-E:D1 5/1/2019
Product Overview System Architecture
Figure 1.2 Single NFN Network Architecture
FACP FACP
IP Network
NFN-GW-EM-3
FACP
Workstation
Workstation
HS-NCM
or
NCM
NFN Network
Ethernet
Ethernet Ethernet
