NFN-GW-EM-3 Installation and Operation Manual — P/N LS10017-000NF-E:D1 5/1/2019 9
System Architecture Product Overview
Figure 1.3 Multiple NFN Networks Architecture
FACP
FACP
NFN Network
NFN-GW-EM-3
FACP
PC Gateway
with Workstation
Workstation
FACP FACP
NFN Network
FACP
Workstation
HS-NCM
or
NCM
Ethernet
Ethernet Ethernet
IP Network
Ethernet
NFN
