Page 2 of 7 — DN-7112:P • 12/20/2020
VOICE FEATURES
• Integrates with FirstCommand Series. See DN-60772.
• Telephone applications require NFC-FFT.
HIGH-EFFICIENCY OFFLINE SWITCHING
3.0 A P
OWER SUPPLY (6.0 A IN ALARM)
• 120 VAC (NFS-320/NFS-320C); 240 VAC (NFS-320E).
• Displays battery current/voltage on panel (with display).
FLASHSCAN
®
INTELLIGENT FEATURES
• Polls up to 318 devices in less than two seconds.
• Activates up to 159 outputs in less than five seconds.
• Multicolor LEDs blink device address during Walk Test.
• Fully digital, high-precision protocol (U.S. Patent 5,539,389).
• Manual sensitivity adjustment — up to nine levels.
• Pre-alarm ONYX intelligent sensing — up to nine levels.
• Day/Night automatic sensitivity adjustment.
• Sensitivity levels:
–Photo – 0.5 to 2.35%/foot obscuration.
– High-Sensitivity Photoelectric (VIEW
®
) – Open Air Protection
(0.5% - 2.0%/ft. obscuration), Special Applications (0.02%-
0.5%/ft. obscuration)
– Multi-Criteria Detector – Open Air Protection (2.52-3.89%/ft.
obscuration), Special Applications (1.13-2.52%/ft. obscuration)
• Drift compensation (U.S. Patent 5,764,142).
• Degraded mode: In the unlikely event that the NFS-320’s primary
microprocessor fails, FlashScan detectors revert to degraded
operation and can activate the control panel’s NAC circuits and
alarm relay. Each of the four built-in panel circuits includes a Dis-
able/Enable switch for this feature.
• Multi-detector algorithm involves nearby detectors in alarm deci-
sion (U.S. Patent 5,627,515).
• Automatic detector sensitivity testing (NFPA-72 compliant).
• Maintenance alert (two levels).
• Self-optimizing pre-alarm.
FSV-951 SERIES VIEW
®
(VERY INTELLIGENT EARLY WARNING)
H
IGH-SENSITIVITY SMOKE DETECTOR
• Advanced ONYX intelligent sensing algorithms differentiate
between smoke and non-smoke signals.
• Addressable operation pinpoints the fire location.
• Ivory models (-IV) support CLIP mode as well as FlashScan.
• ULC listed models available; “A” models are ULC Listed.
• -R is retrofit, backwards compatible for use with older panels.
FCO-951/-IV ADVANCED MULTI-CRITERIA FIRE/CO DETECTOR
• Detects all four major elements of a fire (smoke, heat, CO, and
flame).
• 135°F (57.2°C) fixed-temperature heat detector.
• Transmits an alarm signal due to heat.
• Separate signal for life-safety CO detection.
• Optional addressable sounder base for Temp-3 (fire) or Temp-4
(CO) tone.
• Automatic drift compensation of smoke sensor and CO cell.
• High nuisance-alarm immunity.
• ULC listed models available; -A models are ULC Listed.
FPTI-951(A) INTELLIGENT MULTI-CRITERIA DETECTOR
• Combined photoelectric, thermal, and infrared sensor
• UL 268 7th Edition and UL 521 Listed; Canadian models CAN/
ULC S529 and CAN/ULC S530
• Microprocessor-based technology; combination photo, thermal,
and infrared technology.
FPC-951(A) PHOTOELECTRIC/CO SENSOR
• Combined photoelectric and carbon monoxide sensor
Sample
System
Options
7112blok-2014.wmf
SLC Intelligent Loop
DEVICES
FPTI-951
FSP-951
FST-951
FCO-951
…etc.
NBG-12LX
FMM-1
IDC
FDU-80
LCD2-80
Up to 32 remote displays
EIA-485
EIA-485
EIA-232
2048 annunciator/control points
Optional 318-point UDACT
Dual phone
lines to
Central
Station
ACM/AEM-24AT
LED Annunciator
LDM-32
Custom Graphics
ACM-8R
Relay Control
FCM-1
NAC
FRM-1
Relay Contact
PRN Series
Printer
NFS-320
FWSG
XP6/10
Input/Output Modules
To Next Page
