SPECIFICATIONS
SYSTEM CAPACITY
• Intelligent Signaling Line Circuits .......................................1
• Intelligent detectors .......................................................159
• Addressable monitor/control modules ............................159
• Programmable internal hardware and output circuits ........4
• Programmable software zones.........................................99
• Special programming zones .............................................14
• LCD annunciators per NFS-320/-320E ............................32
• ACS annunciators
per NFS-320/-320E .....................32 addresses x 64 points
ELECTRICAL SPECIFICATIONS
• Primary input power:
– NFS-320: 120 VAC, 50/60 Hz, 5.0 A.
– NFS-320E: 220/240 VAC, 50/60 Hz, 2.5 A.
• Current draw (standby/alarm):
– NFS-320(E) board: 0.250 A. Add 0.035 A for each NAC in use.
– KDM-R2 (Backlight on): 0.100 A.
• Total output 24 V power: 6.0 A in alarm.
NOTE: The power supply has a total of 6.0 A of available power. This is
shared by all internal circuits. See Installation Manual for a complete cur-
rent draw calculation sheet.
• Standard notification circuits (4): 1.5 A each.
• Resettable regulated 24V power: 1.25 A.
• Two non-resettable regulated 24V power outputs:
– 1.25 A.
– 0.50 A.
• Non-resettable 5V power: 0.15 A.
• Battery charger range: 18 AH – 200 AH. Use separate cabinet for
batteries over 26 AH.
• Float rate: 27.6 V.
CABINET SPECIFICATIONS
NFS-320 cabinet dimensions:
• Backbox: 18.12 in. (46.025 cm) width; 18.12 in. (46.025 cm)
height; 5.81 in. (14.76 cm) depth.
• Door: 18.187 in. (46.195 cm) width; 18.40 in. (46.736 cm) height;
0.75 in. (1.905 cm) depth.
• Trim ring: Molding width is 0.905 in. (2.299 cm).
• Shipping weight (without batteries): 36.15 lb. (16.4 kg).
TEMPERATURE AND HUMIDITY RANGES
This system meets NFPA requirements for operation at 0 – 49°C/32
– 120°F and at a relative humidity 93% ± 2% RH (noncondensing) at
32°C ± 2°C (90°F ± 3°F). However, the useful life of the system's
standby batteries and the electronic components may be adversely
affected by extreme temperature ranges and humidity. Therefore, it
is recommended that this system and its peripherals be installed in
an environment with a normal room temperature of 15 – 27°C/60 –
80°F.
AGENCY LISTINGS AND APPROVALS
The listings and approvals below apply to the basic NFS-320 control
panel. In some cases, certain modules may not be listed by certain
approval agencies, or listing may be in process. Consult factory for
latest listing status.
• UL/ULC Listed: S635.
•FM Approved.
• CSFM: 7165-0028:0243.
• MEA: 128-07-E.
• Fire Dept. of New York: COA# 6212.
• City of Chicago.
• ULC Listed: S527-11
NOTE: For additional information on UL- and ULC-listed model NFS-
320C, see DN-60085. For information on NFS-320SYS, see DN-60637.
Marine Applications: Marine approved systems must be config-
ured using components itemized in this document. (See Main Sys-
tem Components, in “Product Line Information.) Specific
connections and requirements for those components are described
in the installation document, PN 54756. When these requirements
are followed, systems are approved by the following agencies:
• US Coast Guard 161.002/50/0, 161.002/55/0 (Standard 46 CFR
and 161.002).
• Lloyd's Register 11/600013 (ENV 3 category).
• American Bureau of Shipping (ABS) Type Approval.
NOTE: For information on marine applications, see DN-60688.
STANDARDS
The NFS-320 complies with the following UL Standards and NFPA
72, International Building Code (IBC), and California Building Code
(CBC) Fire Alarm Systems requirements:
• UL 864 (Fire).
• UL 1076 (Burglary).
• UL 2572 (Mass Notification Systems). (NFS-320 version 20 or
higher).
• ULC-S527-11 Standard for the Installation of Fire Alarm Sys-
tems.
• LOCAL (Automatic, Manual, Waterflow and Sprinkler Supervi-
sory).
• AUXILIARY (Automatic, Manual and Waterflow) (requires TM-4).
• REMOTE STATION (Automatic, Manual, Waterflow and Sprinkler
Supervisory) (requires TM-4).
• PROPRIETARY (Automatic, Manual, Waterflow and Sprinkler
Supervisory). Not applicable for FM.
• CENTRAL STATION (Automatic, Manual, Waterflow and Sprin-
kler Supervisory) (requires DACT).
• EMERGENCY VOICE/ALARM.
• OT, PSDN (Other Technologies, Packet-switched Data Network).
• IBC 2012, IBC 2009, IBC 2006, IBC 2003, IBC 2000 (Seismic).
• CBC 2007 (Seismic).
