Honeywell PRO4200 Series User Manual

10 www.honeywell.com
Installing the PRO4200 Output Module
Specification
Specification
The Output Board is for use in low voltage, class 2 circuits only.
Primary power:
12VDC + 10%, 385mA maximum
Relay contacts:
Relays 0 through 15 outputs, Form-C, 2A @ 28VDC, resistive
Inputs:
Two unsupervised dedicated inputs
Communication:
Wire requirements:
Mechanical:
Environment:
Set Up
RS-485 Range 9,600 to 38,400 bps
Power 1 twisted pair, 18AWG
RS-485
24AWG, 4,000 feet (1,200 m) max., 2 twisted pair with shield (120
,
23pF) (Belden 9842 or equiv.)
Inputs 1 twisted pair per input, 30 ohms max.
Outputs As required for the load
Dimension 5.5" (140 mm) W x 9" (229 mm) L x 1" (25 mm) H
Weight 12 oz. (340 g) nominal
Temperature 0°C to +49°C, operating, -55°C to +85°C, storage
Humidity
0% to 85% RHNC
Table 1: PRO4200 Output Module Jumper Setting
Jumper Setting Default Selected
J1 OFF * Port 1 RS-485 EOL
terminator is not active
ON Port 1 RS-485 EOL
terminator is active
