Cable Assembly Connections
Document 800-08279, Revision A
February 2011
© Honeywell International. All rights reserved.
Here are the three cable assemblies that connect to these pin connectors:
Figure 2: AC Power Inlet and LED Indicator Cable Assembly
Figure 3: 12VDC Power and Battery Cable Assembly
Connects to
CN1
LED
AC Power Inlet
Connects to
CN2
