Honeywell PW7000 Series User Manual

20 www.honeywell.com
PW7K1R1E Wiring and Setup
Specifications
Power • 18 AWG
• 1 twisted pair
Ethernet • CAT-5 (minimum)
RS-485 • 24AWG
• 120-ohm impedance
• 4,000ft (1,220 m) maximum
• Twisted pair(s) with an overall shield
18AWG
Alarm Input • Twisted pair per input
• 30-ohm maximum loop resistance
Reader data (RS-
485)
• 24AWG
• 120-ohm impedance
• Twisted pair with shield
• 4000-foot (1220 m) maximum
• 18AWG*
Environmental
Temperature • -55°C to +85°C, storage
• 0°C to +70°C, operational
Humidity • 5 to 95% RHNC
Mechanical
Dimension • 5.5" (140mm) W x 2.75" (70mm) L x
0.96" (24mm) H without bracket
• 5.5" (140mm) W x 3.63" (92mm) L x
1.33" (34mm) H with bracket
Weight • 4 oz. (112g) without bracket
• 5 oz. (142g) with bracket
UL294, 6th edition Performance Levels
Feature
Level
Stand by Power
I
Endurance
IV
Line Security
I
Destructive Attack
I
