2.16 Additional Mounting Information
Sources for the optional items shown below:
• 3-gang stainless steel blank cover: Leviton part number 84033-40.
Available from Graybar, part number 88158404.
• Magnetic switch set: G.R.I. part number: 505.
Figure 2-6: Stainless Steel Blank Cover
FIELD WIRING
PW-6K1R1E WITH INCLUDED
MOUNTING PLATE
TO ETHERNET
NETWORK
OPTIONAL 3-GANG
JUNCTION BOX
OPTIONAL BLANK
COVER W/SCREWS
To Next Page
