BUILDING NETWORK ADAPTER BNA-1C/2CS/2DN
28 EN1B-0198GE51 R1004B
6.4 Device Setup
In order to setup the BNA device properly, the
following connections are necessary:
• DB9F Null-Modem cable connected to a PC
running a VT100 terminal emulation program or a
VT100 compatible terminal (refer to Table 6-1:
Terminal settings)
• LAN connection via UTP (RJ45 connector).
• Power connection.
• An active FTP-Server machine on the LAN
Terminal type: VT100
Bits per second: 115200
Data bits: 8
Parity: none
Stop bits: 1
Flow control: none
Table 6-1: Terminal settings
After having connected all necessary cables to the
BNA, press the Reset button. If the terminal settings
are all Ok, the Copyright notice of the BNA device
will be displayed.
If this is the very first run of the device, then the
Copyright notice is followed by the query for the
