Honeywell Q7055A Installation Instructions

BUILDING NETWORK ADAPTER BNA-1C/2CS/2DN
44 EN1B-0198GE51 R1004B
7.2 Ethernet Connectors
8-pin modular
(MJ8)
connector RJ-45
Figure 7-3: BNA Ethernet connection
The BNA provides an RJ45 10BaseT connector to
bring the device online on the LAN. This chapter
describes the pin layout of this connector and
shows how the cables must be configured for con-
necting via 10BaseT (RJ45).

Honeywell Q7055A Specifications

General

Brand	Honeywell
Model	Q7055A
Category	Adapter
Language	English
