10
INSTALLATION
Low Speed USB (Integrated)
1. Turn off the host device.
2. Plug the male 10-pin RJ45 end of
the USB PowerLink cable into the
10-pin socket on the IS3480.
3. Plug the other end of the USB
interface cable into the host
device’s USB port.
4. Turn on the host device.
As a default, the IS3480-38
leaves the factory with USB
Keyboard Emulation Mode
enabled.
For information on
configuring the IS3480-38 for
USB Serial Emulation Mode,
please refer to Section P:
Low Speed USB in the
MetroSelect Configuration
Guide (MLPN 00-02407).
When the scanner first receives power, the blue LED will turn on; the
scanner will simultaneously beep once and flash the white LED.
Plugging the scanner into the USB port of the PC does not guarantee
that scanned information will appear at the PC. A software driver and
correct configuration setting are also required for proper
communication to occur.
See page 5.
Figure 8.
