2 ZONE T6R SMART THERMOSTAT
T6R-2Z-EN0H 8603 NL01 R0718
Room
Temperature
display range
T6R (wireless) 108 x 103 x 68 mm
24 hour or 12 hour AM/PM format
Synchronized with Internet when
connected or typically better than 10
minutes per year
5+2 or daily schedule with 6 daily time
and temperature level changes
Program - 10 minute steps
Temperature
setting range
Program : 5 to 37
o
C in 0.5
o
C steps
OFF : 5
o
C
T6R (wireless) 5VDC power adapter
Electrical rating
Relay contacts
230 V~, 50...60 Hz, 0.5 A to 5 A resistive
0.5 A to 3 A inductive (0.6 pf)
24 V~, 50...60 Hz, 0.5 A to 5 A resistive
0.5 A to 3 A inductive (0.6 pf)
Selectable by application (see installer
set up)
Terminal block capable of accepting
wires up to 1.5 mm
2
From back via large wall box opening.
From bottom with cable clamps.
Mains wiring – left.
Low voltage wiring – right.
110 x 110 x 40 mm (w x h x d)
ISM (868.0-868.6) MHz, 1% duty cycle
30 m in a residential building
environment
short, high rate transmissions to
minimise air time and avoid collisions
Factory pre-bound packs
IEEE 802.11b/g/n – 2.4GHz
Environmental and standards
Operating
temperature range
Shipping and storage
temperature
10 to 90% rh, non-condensing
Class VI (+4%), (EU) 811/2013
Honeywell, declares that this thermostat is in compliance
with the essential requirements and other relevant
provisions of Directive 2014/53/EU
