Release 1 34-ST-25-19 RMA 3000 Remote Meter Assemblies User Manual
6/04
11
Application Document Description
Drawing
Number
For intrinsically safe application (FM)
Lightning Protection Option
Sheet 1 – Intrinsically Safe - FM
Sheet 2 – ME (Analog Meter)
Sheet 3 – RMA 3000 - SM
Sheet 4 – RMA 3000 - ME
Non-Lightning Protection Option
Sheet 5 – ME (Analog Meter)
Sheet 6 – RMA 3000 - SM
Sheet 7 – RMA 3000 - ME
51205784
For intrinsically safe application
(CENELEC)*
51450805*
ST 3000 HART Series 100 and 900
Transmitters
(Note – these drawings are also included
in
34-ST-25-17A
Release 300 with HART
Communications Option User Manual
For intrinsically safe application (CSA)
Lightning Protection Option
Sheet 1 – Intrinsically Safe - CSA
Sheet 2 – Communicator
Sheet 3 – ME (Analog Meter)
Sheet 4 – RMA 3000 – SM
Sheet 5 – RMA 3000 - SM
Sheet 6 – RMA 3000 – ME
Sheet 7 – RMA 3000 – ME
Non-Lightning Proof Option
Sheet 8 – ME (Analog Meter)
Sheet 9 – RMA 3000 - SM
Sheet 10 – RMA 3000 - ME
Sheet 11 – RMA 3000 - ME
51450806
* A copy of this drawing is available upon request.
