–Theantennamountingscrewsshouldbetorquedto2.37to2.60N.m(21.0to23.0in-lbs).
–Ifsealingoftheantennaholesisneeded,thenRTVisrecommendedtobeappliedaround
theedgeofeachholebetweenboththeUAV skinandgroundplaneandthegroundplane
andantenna.Ensurethattheantennaremainsinelectricalcontactwiththegroundplane.
Page13
18 Feb 2021
©HoneywellInternationalInc.DonotcopywithoutexpresspermissionofHoneywell.
SYSTEM DESCRIPTION, INSTALLATION, AND MAINTENANCE MANUAL
SMALL SATCOM
