34-SM-03-01
Page 20
SMV 3000 Model Selection Guide 34-ST-16-51
ns
ruc
ons
Select the desired Key Number. The arrow to the right marks the selection available.
Make one selection from each table, I and II, using the column below the proper arrow.
Select as many Table III options as desired (if no options are desired, specify 00).
A dot denotes unrestricted availability. A letter denotes restricted availability.
Restrictions follow Table IV.
ey
um
e
I II III (Optional) IV
_ _ _ _ _ _ - _ _ _ - _ _ _ _ _ - _ _, _ _ _ _ - XXXX
KEY NUMBER Selection Availability
Differential Pressure Range Pressure Range
0-1" / 25" H20 0-2.5 to 0-62.5 mbar 0-100 psia (7.0 bara) SMA110
0-1" / 400" H20 0-2.5 to 0-1000 mbar 0-750 psia (52.5 bara) SMA125
0-1" / 400" H20 0-2.5 to 0-1000 mbar 0-4500 psig (315 barg) SMG170
See 13:TP-3, 4 and 8 for temperature probes.
See 13:TP-9 through 12 for thermowells.
TABLE I - METER BODY
Vent/Drain
Process Heads Valves Barrier
and Plugs Diaphragms
Carbon Steel * 316 St. St. 316 LSS A _ _
Carbon Steel * 316 St. St. Hastelloy C B _ _
Carbon Steel * 316 St. St. Monel C _ _
Material Carbon Steel * 316 St. St. Tantalum D _ _
of 316 St. St. 316 St. St. 316 LSS E _ _
Construction 316 St. St. 316 St. St. Hastelloy C F _ _
316 St. St. 316 St. St. Monel G _ _
316 St. St. 316 St. St. Tantalum H _ _
Hastelloy C Hastelloy C Hastelloy C J _ _
Hastelloy C Hastelloy C Tantalum K _ _
Monel Monel Monel L _ _
Fill Fluid Silicone _ 1 _
CTFE _ 2 _
Process Head 1/4" NPT _ _ A
Configuration 1/2" NPT with Adapter (on 1/4" NPT Head) _ _ H
ttt
* Carbon Steel heads are zinc-plated.
TABLE II
No Selection 00000
