SPYDER MODEL 5 ROOM CONTROLLERS − INSTALLATION GUIDE
5 31-00281ES-01 (EN1B-0664GE51 R0819)
Table 4. Universal input types and characteristics
type 1
type 2
type 3
UI1, UI2, UI3, UI4,
UI5, UI6
UI7, UI8, UI9,
UI10
UI1, UI2, UI3
dry contact (closed: res. <10 kΩ; open: res. > 20 kΩ; max. 0.2 Hz;
pull-up voltage: 10 V)
X
X
--
dry contact (closed: res. <10 kΩ; open: res. > 20 kΩ; max. 0.2 Hz;
pull-up voltage: 24 V);
--
--
X
fast binary (=counter) input with below characteristics.
(max. 30 Hz; pulse ON = min. 16 ms; pulse OFF = min. 16 ms; closed: voltage < 1 V;
open: voltage > 5 V; pull-up voltage: 10 V)
X
X
--
fast binary (=counter) input with below characteristics.
(max. 30 Hz; pulse ON = min. 16 ms; pulse OFF = min. 16 ms; closed: voltage < 1 V;
open: voltage > 5 V; pull-up voltage: 24 V)
--
--
X
0(2) to 10 V
X
X
--
NTC20kΩ
X
--
--
SetPoint and FanSpdSW
X
--
--
NTC10kΩ (Type II)
X
--
--
PT1000 + Ni1000TK5000
--
X
--
Table 5. Analog output types and characteristics
type 1
type 2
type 3
type 4
type 5
output voltage
0-11 V
output current
0-1 mA
0-5 mA
0-10 mA
0-20 mA
-1- +1 mA
min. accuracy
±150 mV
max. ripple
±100 mV
accuracy at zero point
0-200 mV
±150 mV
