SPYDER MODEL 5 ROOM CONTROLLERS − INSTALLATION GUIDE
31-00281ES-01 (EN1B-0664GE51 R0819) 4
Table 2. WEB-RS5N Room Controllers: Overview of terminals and functions (by model)
term.
printing
function
WEB-
RS5N
1, 2
--
--
--
3, 4
24V~, 24V0
Removable 24 VAC power supply input and aux. output voltage (24 VAC) for all triacs
X
3, 4
24V~, 24V0
Aux. output voltage (24 VAC) for all triacs
X
5
TN
Aux. term. for triac neutral wiring (internally connected with terminal 8)
X
6
T~
Triac input voltage (24 VAC for all triacs; triac-switched
X
7
T01
Triac-switched output
X
8
TN
Aux. term. for triac neutral wiring (internally connected with terminal 5)
X
9
T02
Triac-switched output
X
10, 11
RO4, IN4
Output of Relay 4, Input for Relay 4
type 2
12, 13
RN, RN
Aux. terminals for relay neutral wiring
X
14, 15
IN1, RO1
Input for Relay 1, Output of Relay 1
type 1
16, 17
IN2, RO2
Input for Relay 2, Output of Relay 2
type 1
18, 19
IN3, RO3
Input for Relay 3, Output of Relay 3
type 1
20, 21
WM1, WM2
Removable interface for Sylk Bus
X
22, 23,
24, 25
24V~, C2+,
C2-, 24V0
Aux. power (24 VAC 20%, 50/60 Hz), RS485 Modbus interface and corresponding GND
X
26
AO1
Analog Output 1
type 2
27
24V~
24 VAC power for field devices
X
28
GND
Ground for AOs
X
29
AO2
Analog Output 2
type 1
30
AO3
Analog Output 3
type 1
31
24V~
24 VAC power for field devices
X
32
GND
Ground for AOs
X
33
AO4
Analog Output 4
type 1
34
UI1
Universal Input 1
type 1
35
GND
Ground for UIs
X
36
UI2
Universal Input 2
type 1
37
UI3
Universal Input 3
type 1
38
GND
Ground for UIs
X
39
UI4
Universal Input 4
type 1
40, 41,
42
C1+, C1-, GND
Removable BACnet MS/TP interface and corresponding GND
X
Relay output types: See Table 3. Universal input types: Table 4. Analog output types: See Table 5.
-- : Terminal not used.
X : Terminal used.
Type x: Type of an I/O as per its characteristic. Mode details given on each type in following tables.
Table 3. Relay output types and characteristics
type 1
(standard)
type 2
(high in-rush current)
corresponding ROs of WEB-RS5N
RO1, RO2, RO3
RO4
corresponding ROs of WEB-RL6N
RO2, RO3
RO1, RO4
contact
N.O.
N.O.
min. load
5 VAC, 100 mA
24 VAC, 40 mA
switching voltage range
15 to 253 VAC
15 to 253 VAC
max. continuous load at 250 VAC (cos φ = 1)
4 A
10 A
max. continuous load at 250 VAC (cos φ = 0.6)
4 A
10 A
in-rush current (20 ms)
--
80 A
usage
fan motor
fan motor
NOTE: The max. sum load of all relay currents at the same time is 14 A.
