T7200D,E, T7300D,E,F AND Q7300 SERIES 2000 PROGRAMMABLE COMMERCIAL THERMOSTATS AND SUBBASES
63-4355—211
— To advance to the next Installer Setup number, press the
Unoccupied Temp key.
— To return to an Installer Setup number, press the Heat/
Cool Settings key.
— To change a setting, use the increase ▲ ▲ or ▼ ▼ decrease
key.
— To exit the Installer Setup, press the Run Program key.
The Installer Setup is automatically exited if no key
presses are made for four minutes.
NOTE: Be sure to set the thermostat time after exiting the
Installer Setup.
Installer Setup numbers are listed in Table 8.
CAUTION
Possible Equipment Damage.
Fan must be running when system is operating.
Heat pump and electric heat systems must be
configured correctly in Installer Setup 2 to prevent
equipment damage caused by the system running
without the fan.
IMPORTANT
Only configurable numbers are shown on the device.
Example: If the thermostat does not have a system
key, Installer Setup number 12 will not be displayed.
Review Table 8 factory settings and mark any
desired changes in the Actual Setting column. When
the Installer Setup is complete, review the settings to
confirm that they match the system.
Table 8. Thermostat Installer Setup Options.
(continued)
a
Number 2 must be set to 1 to extend fan operation.
Installer
Setup Number
(Press
Unoccupied
Temp key
Factory Setting
Other Choices
(Press ▲ or ▼ key to change)
Actual
Select
to change)
Display Description Display Description
Setting
Not used 1 — — — — —
Fan operation
a
2 0 Conventional
applications where
equipment controls fan
operation in heat mode.
1 Electric heat applications where
thermostat controls fan operation in
heat mode.
Output stages
of heating
3 Depends
on
subbase
Stages of heat. 0, 1, 2,
or 3
0—No heating.
1—One stage of heat.
2—Two stages of heat.
3—Three stages of heat.
Heating cycle
rate
4 4 Stage 1—4 cph. 3, 6, 8 or
9
3—3 cph used for hot water
systems or high efficiency
furnaces.
5 4 Stage 2—4 cph.
6 4 Stage 3—4 cph.
6—6 cph used for conventional
7 4 Emergency heat relay
is on continuously.
Highest stage of heat
cycles at 4 cph
(Q7300C or D only).
systems.
8—8 cph used for conventional
systems.
9—9 cph used for electric heat
systems.
Output stages
of cooling
8 Depends
on
subbase
Stages of cooling. 0, 1, 2
or 3
0—No cooling.
1—One stage of cool.
2—Two stages of cool.
3—Three stages of cool.
Cooling cycle
9 4 Stage 1—4 cph. 3 3—3 cph.
rate
10 4 Stage 2—4 cph.
11 4 Stage 3—4 cph.
System setting
adjustment
(models with
System key)
12 Depends
on model
System selection. 0, 1 or 2 0—System setting key is
operational.
1—Auto setting is disabled.
2—Auto only setting.
Not used 13 — — — — —
Degree
temperature
display
14 0 Temperature is
displayed in °F.
1 Temperature is displayed in °C.
To Next Page
