T7200D,E, T7300D,E,F AND Q7300 SERIES 2000 PROGRAMMABLE COMMERCIAL THERMOSTATS AND SUBBASES
63-4355—2 12
Table 8. Thermostat Installer Setup Options
(Continued).
b
Number 22 must be set to 1 and remote sensor(s) must be installed.
(continued)
Installer
Setup Number
(Press
Unoccupied
Temp key
Factory Setting
Other Choices
(Press ▲ or ▼ key to change)
Actual
Select
to change)
Display Description Display Description
Setting
Displaying
temperature
(T7300F only).
15 0 Temperature is
displayed.
1 Temperature is not displayed.
Clock format. 16 0 12-hour clock format. 1 24-hour clock format.
Intelligent Fan™
operation.
17 2 Fan operates con-
tinuously in Occupied
and recovery modes.
Fan operates with call
for heating or cooling in
Unoccupied mode.
0 or 1 0—Fan only operates with calls for
heating or cooling in Occupied
and Unoccupied modes.
1—Fan operates continuously in
Occupied mode. Fan operates
with calls for heating or cooling
in Unoccupied mode.
Auxiliary contact
operation.
18 0 0—Time of day
contact.
0 or 1 1—Economizer contacts. —
Extended fan
operation in
heating
a
(T7300F only).
19 0 No extended fan
operation after the call
for heat ends.
1 Fan operation is extended
90 seconds after the call for
heat ends.
Extended fan
operation in
cooling (T7300
only).
20 0 No extended fan
operation after the call
for cool ends.
1 Fan operation is extended
90 seconds after the call for
cool ends.
Fan key adjust-
ment (models
with Fan key).
21 0 Fan setting key is
operational.
1 Fan setting key is Auto only.
Remote sensing. 22 0 Remote sensing not
activated.
1 Remote sensing activated.
Temperature
averaging
network
b
(T7300
only).
23 0 Temperature averaging
disabled.
1 Temperature averaging between
local sensor and remote sensor(s)
activated.
Not used. 24 — — — — —
Keypad lockout
level (keypad
lockout is
enabled and
disabled by DIP
switch 1 on
back of
thermostat).
25 0 No lockout. 1 or 2 1—Lockout all keys on thermostat
except system and fan settings,
temporary setpoint, clock and
day adjustments, increase ▲ and
▼ decrease keys.
2— Lockout all keys except Set
Current Day/Time, increase ▲
and decrease ▼ keys.
3—Lockout all keys except
Temporary Occupied and Set
Current Day/Time (for clock, day
adjustment).
Duration of
temporary
override.
26 3 3—Three hour
override.
1, 8 or 12 1—One hour override.
8—Eight hour override.
12—Twelve hour override.
Not used. 27 thru 29 — — — — —
Deadband
(T7300F only).
30 2 Heating and cooling
setpoints can be set no
closer than 2°F (1.1°C).
3 thru 10 Heating and cooling setpoints can
be set no closer than the chosen
value.
To Next Page
