Honeywell T7350 System Engineering

T7350 COMMERCIAL PROGRAMMABLE THERMOSTAT
15 63-4368
General Considerations
Table 8 lists wiring types, sizes and distances for the T7350
and Excel 10 products. The T7350 terminal strip accepts 18
through 22 AWG (0.82 to 0.34 sq. mm) wire.
Table 8. Field Wiring Reference.
NOTE: 1. The X, RH and RC terminals will accept 14 to 22 AWG. 14 and 16 AWG should be avoided since the stiff cable
interferes with the cover to subbase installation.
Wire Function
Recommended Wire
Size (Minimum)
Specification or
Requirement
Honeywell Part
Number Distance (Maximum)
Digital Outputs:
W Y G AUX X
18 AWG (0.82 sq mm)
five wire cable bundle.
Standard thermostat
wire.
AK3726 1000 feet.
Modulating Outputs:
MX MH MC
18 AWG (0.82 sq mm) 1 pair per output. AK3757C, AK3744C,
AK3741A, AK3702x
1000 feet.
Remote Humidity
Sensor:
HS HC HP
18 to 22 AWG
(0.82 to 0.34 sq mm)
3 wires. AK3746C, AK3724,
AK3703x
500 feet.
Discharge Air
Temperature Sensor:
AS
18 to 22 AWG
(0.82 to 0.34 sq mm)
1 pair. AK4606ABE,
AK4628AWH,
AK3702x, AK3741A,
AK3744C, AK3757C
1000 feet.
Outdoor Air
Temperature Sensor:
OS
18 AWG (0.82 sq mm) 1 pair. AK3757C, AK3744C,
AK3741A, AK3702x
500 feet.
Motion Sensor:
M
18 to 22 AWG
(0.82 to 0.34 sq mm)
1 pair. AK4606ABE,
AK4628AWH,
AK3702x, AK3741A,
AK3744C, AK3757C
1000 feet.
Wall Module
connections:
T3-T7
18 to 22 AWG
(0.82 to 0.34 sq mm)
Twisted pair wire is
recommended for wire
runs longer than 100
ft. The number of pairs
depends on the model
and functions
selected.
AK4606ABE,
AK4628AWH,
AK3702x, AK3741A,
AK3744C, AK3757C,
AK3726
1000 feet.
Power Wiring to:
X RH RC
18 to 14
1
AWG
(0.82 to 2.0 sq mm)
use heavier wire for
longer runs.
NEC Class II,
140°F (60°C) rating.
AK3702x, AK3741A,
AK3744C, AK3757C,
AK3712x, AK3754
Limited by line-loss
effects on power
consumption.
L
ONWORKS
®
Bus
(Non-Plenum).
22 AWG
(0.34 sq mm)
Nema Level IV
U.L. Type CMR
Twisted pair stranded
conductor,
nonshielded.
AK3798 (1 pair) Refer to E-bus Wiring
Guidelines Users
Guide 74-2865 for
maximum length and
generic cable
specifications.
LONWORKS
®
Bus
(Plenum Rated).
22 AWG
(0.34 sq mm)
Nema Level IV
U.L. Type CMP
Twisted pair stranded
conductor,
nonshielded.
AK3797 (1 pair)
AK3799 (2 pair)
—
