Honeywell TH7000 Series Installation Guide

Installation Guide
2
69-2668—03
MCR31514
M28073
Wallplate installation
1. Separatewallplatefromthermostat.
2. Mount wallplate as shown below.
MERCURY NOTICE
Ifthisproductisreplacingacontrolthatcontainsmercuryinasealedtube,donot
placetheoldcontrolinthetrash.Contactyourlocalwastemanagementauthorityfor
instructions regarding recycling and proper disposal.
Grasptopandbottomofwallplate
andpulltoremovefromthermostat.
CAUTION: ELECTRICAL HAZARD
Cancauseelectricalshockorequipmentdamage.Disconnectpowerbefore
beginning installation.
Drill3/16”holesfordrywall.
Drill7/32”holesforplaster.
Wallanchors
Wirehole Mounting screws
Must be installed by a trained, experienced technician
• Readtheseinstructionscarefully.Failuretofollowtheseinstructions
can damage the product or cause a hazardous condition.
