Honeywell TH7000 Series Installation Guide

TH7000 Series
7
69-2668—03
0120 Year
(rst two digits)
20 (2000-2099)
21 (2101-2178)
0130 Year
(second two digits)
12 (2012)
 [Otheroptions:00-99]
0140 Month 6 [Otheroptions:1-12]
0150 Date 15 [Otheroptions:1-31]
0160 Schedule format 4 7-day programming
0 Non-programmable
0165 Restore energy saving
schedule
0 Continue using programmed schedule.
1 Restore thermostat program to energy saving settings.
0170 System type 1 1 heat/1 cool conventional
2 1 heat/1 cool heat pump (no aux. heat)
3 Heat only (2-wire systems)
4 Heatonlywithfan
5 HotwaterSeries20system(powertoopen&closezone
valves/normally open zone valves)
6 Cool only
7 2heat/1coolheatpump(withaux.heat)
8 2 heat/2 cool multistage conventional
9 2heat/1coolmultistageconventional
10 1 heat/2 cool multistage conventional
0180 Fan control
(heating)
0 Gas/Oil heat (equipment controls heating fan)
1 Electricfurnace(thermostatcontrolsheatingfan)
0190 Changeover valve
(O/B terminal)
0 O/B terminal controls valve in cooling
1 O/B terminal controls valve in heating
0200 Auxiliary heat 0 Electric backup heat
1 Fossilfuelbackupheat
0210 External fossil
fuel kit
1 External fossil fuel kit controls backup heat
0 Thermostat controls backup heat (outdoor sensor required)
0220 1st stage com-
pressor cycle rate
3 Recommended for most compressors
 [Otheroptions:1,2,4,5or6CPH]
0230 2nd stage com-
pressor cycle rate
3 Recommended for most compressors
 [Otheroptions:1,2,4,5or6CPH]
Setup functions Settings & Options (factorydefaultinbold)
Shaded areas below apply only to TH7220.
Continued on next page
