11 69-2072—09
Wiring
Wiring TrueIAQ
®
with a non-powered humidifier.
HVAC
M32534
68
40
55
12 15
:
76
%
%
In
Out
PM
R
C
W
Y
G
R
C
SENSOR
SENSOR
SWITCH
W
G
VENT
VENT
DEHUM
DEHUM
HUM
HUM
24V
TRANSFORMER
HE100, HE200
BYPASS
HUMIDIFIER
TrueIAQ
+
–
OUTDOOR
SENSOR
THERMOSTAT
