Honeywell TrueIAQ - Wiring with Powered Humidifier

69-2072—09 12
Wiring
Wiring TrueIAQ
®
with a powered humidifier.
HVAC
THERMOSTAT
M32535
68
40
55
12 15
:
76
%
%
In
Out
PM
R
C
W
Y
G
R
C
SENSOR
SENSOR
SWITCH
W
G
VENT
VENT
DEHUM
DEHUM
HUM
HUM
HE150, HE250,
HE300, BYPASS
HUMIDIFIER
TrueIAQ
OUTDOOR
SENSOR
HUM
HUM
