T8205B,C, TS8205B,C ELECTRONIC POOL, SPA CONTROL SYSTEMS;
T8205A,H, TS8205A CONTROL MODULES; Q8205A-C SETPOINT PANELS AND SENSOR ASSEMBLY
68-0177—1
3
Panel Potentiometers
Switch
Positions LED
Q8205A 1 none none
Q8205B 1 On-Off none
Q8205C 2 Pool-Off-Spa optional
Table 4. Q8205A-C Setpoint Panels.
Electrical Ratings:
T8205 Power Supply: 18-30 Vac, 60 Hz.
T8205 Power Consumption: 3 VA at 24 Vac.
TS8205 Power Supply: 750 mV, dc.
Relay Contacts: Inductive: 2A full load, 10A locked rotor.
Resistive: 2A.
Temperature Setting Range:
61° to 106°F (16° to 41°C).
Setpoint Adjustment:
10K ohm, one-turn potentiometer.
Setpoint Accuracy:
±1.5°F (0.8°C) at 106°F (41°C).
Ambient Temperature Range at Module:
T8205: -40° to +175°F (-40° to + 80°C).
TS8205: 0 to 175°F (0° to 80°C).
Differential (Not field adjustable):
1°F (0.7°C) maximum at 106°F (41°C), subtractive.
Sensor:
NTC thermistor sensor is imbedded in a copper bulb. Includes
leadwires with 3/16 in. female quick connects.
See Table 5.
Mounting:
T8205B,C and TS8205B,C Control Systems are mounted
on the appliance through mounting holes on the device.
Sensors are mounted directly into the header or in a
well.
IMPORTANT
T8205A,H, TS8205A Control Modules and Q8205A-
C Setpoint Panels must be mounted to allow
adequate electrical spacing according to approval
agency requirements.
T8205A,H and TS8205A Control Modules mount on any
flat surface using no. 6 screws (obtained locally)
through mounting holes.
Q8205A-C Setpoint Panels mount through holes on board
using no. 6 screws (obtained locally).
Sensing Bulb:
Can be mounted in immersion well or directly immersed,
using fittings to prevent leakage. Well or fitting supplied by
heater manufacturer.
Approvals:
International Approval Services (American Gas
Association and Canadian Gas Association) (IAS)
Certificate: C2030021.
Meets ANSI Standard Z21.23-1993.
Accessory:
Part no. 107408 Heat Conductive Compound in 4 oz. can.
Use when mounting sensor in a well.
Optional Features:
T8205B,C: LED indicator available for Heat-On indication.
Specify when ordering.
Dimensions:
See Fig. 1 for T8205B,C; TS8205B,C; Q8205A; T8205A,H;
TS8205A dimensions. See Table 5 for sensor dimensions.
Table 5. Sensors.
Sensor Termination Lead Length Diameter Capsule Length Mounting Material
198799E 3/16 in. quick connect 42 in. (1067 mm) 3/8 in. (10 mm) 2 in. (51 mm) Compression Copper
198799F 1/4 in. quick connect 48 in. (1219 mm) 3/8 in. (10 mm) 3 in. (76 mm) Compression Copper
198799H 3/16 in. quick connect 42 in. (1067 mm) 3/8 in. (10 mm) 2-5/8 in. (67 mm) Spud Copper
198799K 3/16 in. quick connect 42 in. (1067 mm) 3/8 in. (10 mm) 2 in. (51 mm) Compression Monel
198799R 3/16 in. quick connect 48 in. (1219 mm) 3/8 in. (10 mm) 3 in. (76 mm) Compression Copper
198799S 3/16 in. quick connect 96 in. (2438 mm) 3/8 in. (10 mm) 2-5/8 in. (67 mm) Spud Copper
198799W 3/16 in. quick connect 50 in. (1270 mm) 3/8 in. (10 mm) 2 in. (51 mm) Compression Copper
