T8205B,C, TS8205B,C ELECTRONIC POOL, SPA CONTROL SYSTEMS;
T8205A,H, TS8205A CONTROL MODULES; Q8205A-C SETPOINT PANELS AND SENSOR ASSEMBLY
ORDERING INFORMATION
When purchasing replacement and modernization products from your wholesaler or your distributor, refer to the price sheets for
complete ordering number, or specify:
1. Order numbers for Control System and Sensor Assembly; or Control Module, Setpoint Panel and Sensor Assembly.
2. Leadwire length for Q8205A-C.
3. For T8205B,C: Heat-On LED, LED Terminal and N.C. Contacts, as desired. See Table 2 for availability.
4. For T8205A, TS8205A, Q8205A-C optional features as desired. See Tables 3 and 4 for availability.
5. Accessories, if required.
If you have additional questions, need further information, or would like to comment on our products or services, please write or
phone:
1. Your local Honeywell Home and Building Control Sales Office (check white pages of phone directory).
2. Home and Building Control Customer Logistics
Honeywell Inc., 1985 Douglas Drive North
Minneapolis, Minnesota 55422-4386
In Canada—Honeywell Limited/Honeywell Limitée, 35 Dynamic Drive, Scarborough, Ontario M1V 4Z9.
International Sales and Service Offices in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France,
Germany, Japan, Mexico, Netherlands, Spain, Taiwan, United Kingdom, U.S.A.
SPECIFICATIONS
IMPORTANT
The specifications given in this publication do not
include normal manufacturing tolerances. Therefore,
this unit may not exactly match the listed
specifications. Also, this product is tested and
calibrated under closely controlled conditions, and
some minor differences in performance can be
expected if those conditions are changed.
Models:
T8205B,C and TS8205B,C Electronic Pool, Spa and Hot
Tub Control Systems provide single or dual water
temperature control in pool, spa, or hot tub applications.
Order Sensor Assembly separately. See Table 5.
T8205B,C and TS8205B,C include electronic control
module and setpoint panel with one or two
potentiometers with selector switch, and on select
models, an LED Heat-On display. See Tables 1
through 3.
T8205A,H, TS8205A Control Modules available separately.
See Table 3.
T8205H is for use with Heat Pump Systems only.
Q8205A,B,C Setpoint Panels available separately for
remote applications. See Table 4.
Separate Components:
To order components separately, see Tables 3 through 5.
Table 1. T8205B,C 24 Vac Control Systems
Table 2. TS8205B,C Millivolt Control Systems. Table 3. T8205A/TS8205A Control Modules.
Control System Control Rating Potentiometers Switch Positions Heat-On LED LED Terminal N.C. Contacts
T8205B 24 Vac 1 On-Off yes yes yes
T8205B 24 Vac 1 On-Off no no no
T8205C 24 Vac 2 Pool-Off-Spa no no no
T8205C 24 Vac 2 Pool-Off-Spa no yes no
T8205C 24 Vac 2 Pool-Off-Spa yes yes no
T8205C 24 Vac 2 Pool-Off-Spa yes yes yes
Control
System
Control
Rating Potentiometers
Switch
Positions
TS8205B 750 mV 1 On-Off
TS8205C 750 mV 2 Pool-Off-Spa
Control
Module
Control
Rating Contacts
LED
Terminal
T8205A 24 Vac N.C.—optional optional
T8205H 24 Vac N.O./N.C. not available
TS8205A 750 mV not available not available
